2021 Vol. 10, No. 3

News & Views
Exciton diffusion exceeding 1 µm: run, exciton, run!
Ibrahim Dursun, Burak Guzelturk
Published. 2021, 10(3) : 304-306 doi: 10.1038/s41377-021-00480-2
Exciton diffusion lengths reaching the micrometer length scale have long been desired in solution-processed semiconductors but have remained unattainable using conventional materials to date. Now halide perovskite nanocrystal films show unprecedented exciton migration with diffusion lengths approaching 1 µm owing to the efficient combination of radiative and nonradiative energy transfer.
Subwavelength hybrid plasmonic structures for nonlinear nanophotonics
Ann-Katrin U. Michel
Published. 2021, 10(3) : 307-309 doi: 10.1038/s41377-021-00479-9
Plasmonic structures made of a semiconductor-insulator-metal hybrid provide efficient routes for second-harmonic and sum-frequency generation in sub-micrometer structures, which ultimately may boost on-chip integrated plasmonic circuits.
Towards next generation white LEDs: optics-electronics synergistic effect in a single-layer heterophase halide perovskite
Andrey L. Rogach
Published. 2021, 10(3) : 310-312 doi: 10.1038/s41377-021-00488-8
A novel concept of the heterophase optics-electronics synergistic effect has been demonstrated in a single-layer a/d-heterophase perovskite CsPbI3 in order to realize white LEDs featuring only one broadband emissive layer.
Bright, high-repetition-rate water window soft X-ray source enabled by nonlinear pulse self-compression in an antiresonant hollow-core fibre
M. Gebhardt, T. Heuermann, R. Klas, C. Liu, A. Kirsche, et al.
Published. 2021, 10(3) : 313-319 doi: 10.1038/s41377-021-00477-x
Bright, coherent soft X-ray radiation is essential to a variety of applications in fundamental research and life sciences. To date, a high photon flux in this spectral region can only be delivered by synchrotrons, free-electron lasers or high-order harmonic generation sources, which are driven by kHz-class repetition rate lasers with very high peak powers. Here, we establish a novel route toward powerful and easy-to-use SXR sources by presenting a compact experiment in which nonlinear pulse self-compression to the few-cycle regime is combined with phase-matched high-order harmonic generation in a single, helium-filled antiresonant hollow-core fibre. This enables the first 100 kHz-class repetition rate, table-top soft X-ray source that delivers an application-relevant flux of 2.8 × 106 photon s−1 eV−1 around 300 eV. The fibre integration of temporal pulse self-compression (leading to the formation of the necessary strong-field waveforms) and pressure-controlled phase matching will allow compact, high-repetition-rate laser technology, including commercially available systems, to drive simple and cost-effective, coherent high-flux soft X-ray sources.
Robust and ultralow-energy-threshold ignition of a lean mixture by an ultrashort-pulsed laser in the filamentation regime
Hongwei Zang, Helong Li, Wei Zhang, Yao Fu, Shanming Chen, et al.
Published. 2021, 10(3) : 320-326 doi: 10.1038/s41377-021-00496-8
Laser ignition (LI) allows for precise manipulation of ignition timing and location and is promising for green combustion of automobile and rocket engines and aero-turbines under lean-fuel conditions with improved emission efficiency; however, achieving completely effective and reliable ignition is still a challenge. Here, we report the realization of igniting a lean methane/air mixture with a 100% success rate by an ultrashort femtosecond laser, which has long been regarded as an unsuitable fuel ignition source. We demonstrate that the minimum ignition energy can decrease to the sub-mJ level depending on the laser filamentation formation, and reveal that the resultant early OH radical yield significantly increases as the laser energy reaches the ignition threshold, showing a clear boundary for misfire and fire cases. Potential mechanisms for robust ultrashort LI are the filamentation-induced heating effect followed by exothermal chemical reactions, in combination with the line ignition effect along the filament. Our results pave the way toward robust and efficient ignition of lean-fuel engines by ultrashort-pulsed lasers.
Green revolution in electronic displays expected to ease energy and health crises
Yuyang Wang, Hui Nie, Jinsong Han, Yaxun An, Yu-Mo Zhang, et al.
Published. 2021, 10(3) : 327-340 doi: 10.1038/s41377-020-00455-9
The technological revolution of long-awaited energy-saving and vision-friendly displays represented by bistable display technology is coming. Here we discuss methods, challenges, and opportunities for implementing bistable displays in terms of molecular design, device structure, further expansion, and required criteria, hopefully benefiting the light-related community.
Ultrahigh-density spin-polarized hydrogen isotopes from the photodissociation of hydrogen halides: new applications for laser-ion acceleration, magnetometry, and polarized nuclear fusion
Alexandros K. Spiliotis, Michalis Xygkis, Michail E. Koutrakis, Konstantinos Tazes, Gregoris K. Boulogiannis, et al.
Published. 2021, 10(3) : 341-351 doi: 10.1038/s41377-021-00476-y
Recently, our group produced spin-polarized hydrogen (SPH) atoms at densities of at least 1019 cm-3 from the photodissociation of hydrogen halide molecules with circularly polarized UV light and measured them via magnetization-quantum beats with a pickup coil. These densities are approximately 7 orders of magnitude higher than those produced using conventional methods, opening up new fields of application, such as ultrafast magnetometry, the production of polarized MeV and GeV particle beams, such as electron beams with intensities approximately 104 higher than current sources, and the study of polarized nuclear fusion, for which the reaction cross sections of D-T and D-3He reactions are expected to increase by 50% for fully polarized nuclear spins. We review the production, detection, depolarization mechanisms, and potential applications of high-density SPH.
Review of biosensing with whispering-gallery mode lasers
Nikita Toropov, Gema Cabello, Mariana P. Serrano, Rithvik R. Gutha, Matías Rafti, et al.
Published. 2021, 10(3) : 352-370 doi: 10.1038/s41377-021-00471-3
Lasers are the pillars of modern optics and sensing. Microlasers based on whispering-gallery modes (WGMs) are miniature in size and have excellent lasing characteristics suitable for biosensing. WGM lasers have been used for label-free detection of single virus particles, detection of molecular electrostatic changes at biointerfaces, and barcode-type live-cell tagging and tracking. The most recent advances in biosensing with WGM microlasers are described in this review. We cover the basic concepts of WGM resonators, the integration of gain media into various active WGM sensors and devices, and the cutting-edge advances in photonic devices for micro- and nanoprobing of biological samples that can be integrated with WGM lasers.
A vacuum ultraviolet laser with a submicrometer spot for spatially resolved photoemission spectroscopy
Yuanhao Mao, Dong Zhao, Shen Yan, Hongjia Zhang, Juan Li, et al.
Published. 2021, 10(3) : 371-378 doi: 10.1038/s41377-021-00463-3
Vacuum ultraviolet (VUV) lasers have demonstrated great potential as the light source for various spectroscopies, which, if they can be focused into a small beam spot, will not only allow investigation of mesoscopic materials and structures but also find application in the manufacture of nano-objects with excellent precision. In this work, we report the construction of a 177 nm VUV laser that can achieve a record-small (~0.76 μm) focal spot at a long focal length (~45 mm) by using a flat lens without spherical aberration. The size of the beam spot of this VUV laser was tested using a metal grating and exfoliated graphene flakes, and we demonstrated its application in a fluorescence spectroscopy study on pure and Tm3+-doped NaYF4 microcrystals, revealing a new emission band that cannot be observed in the traditional up-conversion process. In addition, this laser system would be an ideal light source for spatially and angle-resolved photoemission spectroscopy.
Organic photovoltaics for simultaneous energy harvesting and high-speed MIMO optical wireless communications
Iman Tavakkolnia, Lethy K. Jagadamma, Rui Bian, Pavlos P. Manousiadis, Stefan Videv, et al.
Published. 2021, 10(3) : 379-389 doi: 10.1038/s41377-021-00487-9
We show that organic photovoltaics (OPVs) are suitable for high-speed optical wireless data receivers that can also harvest power. In addition, these OPVs are of particular interest for indoor applications, as their bandgap is larger than that of silicon, leading to better matching to the spectrum of artificial light. By selecting a suitable combination of a narrow bandgap donor polymer and a nonfullerene acceptor, stable OPVs are fabricated with a power conversion efficiency of 8.8% under 1 Sun and 14% under indoor lighting conditions. In an optical wireless communication experiment, a data rate of 363 Mb/s and a simultaneous harvested power of 10.9 mW are achieved in a 4-by-4 multiple-input multiple-output (MIMO) setup that consists of four laser diodes, each transmitting 56 mW optical power and four OPV cells on a single panel as receivers at a distance of 40 cm. This result is the highest reported data rate using OPVs as data receivers and energy harvesters. This finding may be relevant to future mobile communication applications because it enables enhanced wireless data communication performance while prolonging the battery life in a mobile device.
Unsupervised content-preserving transformation for optical microscopy
Xinyang Li, Guoxun Zhang, Hui Qiao, Feng Bao, Yue Deng, et al.
Published. 2021, 10(3) : 390-400 doi: 10.1038/s41377-021-00484-y
The development of deep learning and open access to a substantial collection of imaging data together provide a potential solution for computational image transformation, which is gradually changing the landscape of optical imaging and biomedical research. However, current implementations of deep learning usually operate in a supervised manner, and their reliance on laborious and error-prone data annotation procedures remains a barrier to more general applicability. Here, we propose an unsupervised image transformation to facilitate the utilization of deep learning for optical microscopy, even in some cases in which supervised models cannot be applied. Through the introduction of a saliency constraint, the unsupervised model, named Unsupervised content-preserving Transformation for Optical Microscopy (UTOM), can learn the mapping between two image domains without requiring paired training data while avoiding distortions of the image content. UTOM shows promising performance in a wide range of biomedical image transformation tasks, including in silico histological staining, fluorescence image restoration, and virtual fluorescence labeling. Quantitative evaluations reveal that UTOM achieves stable and high-fidelity image transformations across different imaging conditions and modalities. We anticipate that our framework will encourage a paradigm shift in training neural networks and enable more applications of artificial intelligence in biomedical imaging.
Spontaneously coherent orbital coupling of counterrotating exciton polaritons in annular perovskite microcavities
Jun Wang, Huawen Xu, Rui Su, Yutian Peng, Jinqi Wu, et al.
Published. 2021, 10(3) : 401-408 doi: 10.1038/s41377-021-00478-w
Exciton-polariton condensation is regarded as a spontaneous macroscopic quantum phenomenon with phase ordering and collective coherence. By engineering artificial annular potential landscapes in halide perovskite semiconductor microcavities, we experimentally and theoretically demonstrate the room-temperature spontaneous formation of a coherent superposition of exciton-polariton orbital states with symmetric petal-shaped patterns in real space, resulting from symmetry breaking due to the anisotropic effective potential of the birefringent perovskite crystals. The lobe numbers of such petal-shaped polariton condensates can be precisely controlled by tuning the annular potential geometry. These petal-shaped condensates form in multiple orbital states, carrying locked alternating π phase shifts and vortex-antivortex superposition cores, arising from the coupling of counterrotating exciton-polaritons in the confined circular waveguide. Our geometrically patterned microcavity exhibits promise for realizing room-temperature topological polaritonic devices and optical polaritonic switches based on periodic annular potentials.
Nanoprinted high-neuron-density optical linear perceptrons performing near-infrared inference on a CMOS chip
Elena Goi, Xi Chen, Qiming Zhang, Benjamin P. Cumming, Steffen Schoenhardt, et al.
Published. 2021, 10(3) : 409-419 doi: 10.1038/s41377-021-00483-z
Optical machine learning has emerged as an important research area that, by leveraging the advantages inherent to optical signals, such as parallelism and high speed, paves the way for a future where optical hardware can process data at the speed of light. In this work, we present such optical devices for data processing in the form of single-layer nanoscale holographic perceptrons trained to perform optical inference tasks. We experimentally show the functionality of these passive optical devices in the example of decryptors trained to perform optical inference of single or whole classes of keys through symmetric and asymmetric decryption. The decryptors, designed for operation in the near-infrared region, are nanoprinted on complementary metal-oxide-semiconductor chips by galvo-dithered two-photon nanolithography with axial nanostepping of 10 nm1, 2, achieving a neuron density of > 500 million neurons per square centimetre. This power-efficient commixture of machine learning and on-chip integration may have a transformative impact on optical decryption3, sensing4, medical diagnostics5 and computing6, 7.
Broadband vectorial ultrathin optics with experimental efficiency up to 99% in the visible region via universal approximators
F. Getman, M. Makarenko, A. Burguete-Lopez, A. Fratalocchi
Published. 2021, 10(3) : 420-433 doi: 10.1038/s41377-021-00489-7
Integrating conventional optics into compact nanostructured surfaces is the goal of flat optics. Despite the enormous progress in this technology, there are still critical challenges for real-world applications due to the limited operational efficiency in the visible region, on average lower than 60%, which originates from absorption losses in wavelength-thick (≈ 500?nm) structures. Another issue is the realization of on-demand optical components for controlling vectorial light at visible frequencies simultaneously in both reflection and transmission and with a predetermined wavefront shape. In this work, we developed an inverse design approach that allows the realization of highly efficient (up to 99%) ultrathin (down to 50?nm thick) optics for vectorial light control with broadband input-output responses in the visible and near-IR regions with a desired wavefront shape. The approach leverages suitably engineered semiconductor nanostructures, which behave as a neural network that can approximate a user-defined input-output function. Near-unity performance results from the ultrathin nature of these surfaces, which reduces absorption losses to near-negligible values. Experimentally, we discuss polarizing beam splitters, comparing their performance with the best results obtained from both direct and inverse design techniques, and new flat-optics components represented by dichroic mirrors and the basic unit of a flat-optics display that creates full colours by using only two subpixels, overcoming the limitations of conventional LCD/OLED technologies that require three subpixels for each composite colour. Our devices can be manufactured with a complementary metal-oxide-semiconductor (CMOS)-compatible process, making them scalable for mass production at low cost.
Real-time observation of frequency Bloch oscillations with fibre loop modulation
Hao Chen, NingNing Yang, Chengzhi Qin, Wenwan Li, Bing Wang, et al.
Published. 2021, 10(3) : 434-442 doi: 10.1038/s41377-021-00494-w
Bloch oscillations (BOs) were initially predicted for electrons in a solid lattice to which a static electric field is applied. The observation of BOs in solids remains challenging due to the collision scattering and barrier tunnelling of electrons. Nevertheless, analogies of electron BOs for photons, acoustic phonons and cold atoms have been experimentally demonstrated in various lattice systems. Recently, BOs in the frequency dimension have been proposed and studied by using an optical micro-resonator, which provides a unique approach to controlling the light frequency. However, the finite resonator lifetime and intrinsic loss hinder the effect from being observed practically. Here, we experimentally demonstrate BOs in a synthetic frequency lattice by employing a fibre-loop circuit with detuned phase modulation. We show that a detuning between the modulation period and the fibre-loop roundtrip time acts as an effective vector potential and hence a constant effective force that can yield BOs in the modulation-induced frequency lattices. With a dispersive Fourier transformation, the pulse spectrum can be mapped into the time dimension, and its transient evolution can be precisely measured. This study offers a promising approach to realising BOs in synthetic dimensions and may find applications in frequency manipulations in optical fibre communication systems.
Time-expanded phase-sensitive optical time-domain reflectometry
Miguel Soriano-Amat, Hugo F. Martins, Vicente Durán, Luis Costa, Sonia Martin-Lopez, et al.
Published. 2021, 10(3) : 443-454 doi: 10.1038/s41377-021-00490-0
Phase-sensitive optical time-domain reflectometry (ΦOTDR) is a well-established technique that provides spatio-temporal measurements of an environmental variable in real time. This unique capability is being leveraged in an ever-increasing number of applications, from energy transportation or civil security to seismology. To date, a wide number of different approaches have been implemented, providing a plethora of options in terms of performance (resolution, acquisition bandwidth, sensitivity or range). However, to achieve high spatial resolutions, detection bandwidths in the GHz range are typically required, substantially increasing the system cost and complexity. Here, we present a novel ΦOTDR approach that allows a customized time expansion of the received optical traces. Hence, the presented technique reaches cm-scale spatial resolutions over 1 km while requiring a remarkably low detection bandwidth in the MHz regime. This approach relies on the use of dual-comb spectrometry to interrogate the fibre and sample the backscattered light. Random phase-spectral coding is applied to the employed combs to maximize the signal-to-noise ratio of the sensing scheme. A comparison of the proposed method with alternative approaches aimed at similar operation features is provided, along with a thorough analysis of the new trade-offs. Our results demonstrate a radically novel high-resolution ΦOTDR scheme, which could promote new applications in metrology, borehole monitoring or aerospace.
