2020 Vol. 9, No. 5

News and Views
Polarization-controlled optical holography using flat optics
Arka Majumdar, Shane Colburn
Published. 2020, 9(5) : 1293-1294 doi: 10.1038/s41377-020-00373-w
Due to the large number of degrees of freedom offered by nanoscale scatterers, a single flat optic can project different images at different distances depending on the polarization of the light, opening up opportunities for optical encryption and augmented reality systems.
Light-emitting diodes: brighter NIR-emitting phosphor making light sources smarter
Rong-Jun Xie
Published. 2020, 9(5) : 1295-1296 doi: 10.1038/s41377-020-00394-5
A brighter near-infrared (NIR) phosphor is achieved by inhibiting the oxidation of Cr3+ and reducing the surface defects of phosphor particles, enabling the realization of smarter and more sensitive light sources for night vision.
Hydrodynamical self-interference of a scattered polariton quanta
Jiahui Huang, Wei Liu, Chee Wei Wong
Published. 2020, 9(5) : 1297-1298 doi: 10.1038/s41377-020-00397-2
Researchers have observed the free-propagation of a single microcavity polariton directly and its self-interference when scattering upon a defect. These experimental observations of quantum hydrodynamics in the single polariton limit test the wave-particle duality and aid in the development of polariton-based photonic circuits in quantum information processing.
Multifocal photoacoustic microscopy using a single-element ultrasonic transducer through an ergodic relay
Yang Li, Terence T. W. Wong, Junhui Shi, Hsun-Chia Hsu, Lihong V. Wang
Published. 2020, 9(5) : 1299-1305 doi: 10.1038/s41377-020-00372-x
Optical-resolution photoacoustic microscopy (OR-PAM) has demonstrated high-spatial-resolution imaging of optical absorption in biological tissue. To date, most OR-PAM systems rely on mechanical scanning with confocally aligned optical excitation and ultrasonic detection, limiting the wide-field imaging speed of these systems. Although several multifocal OR-PA (MFOR-PA) systems have attempted to address this limitation, they are hindered by the complex design in a constrained physical space. Here, we present a two-dimensional (2D) MFOR-PAM system that utilizes a 2D microlens array and an acoustic ergodic relay. Using a single-element ultrasonic transducer, this system can detect PA signals generated from 400 optical foci in parallel and then raster scan the optical foci patterns to form an MFOR-PAM image. This system improves the imaging resolution of an acoustic ergodic relay system from 220 to 13 μm and enables 400-folds shorter scanning time than that of a conventional OR-PAM system at the same resolution and laser repetition rate. We demonstrated the imaging ability of the system with both in vitro and in vivo experiments.
Dynamic full-field optical coherence tomography: 3D live-imaging of retinal organoids
Jules Scholler, Kassandra Groux, Olivier Goureau, José-Alain Sahel, Mathias Fink, et al.
Published. 2020, 9(5) : 1306-1314 doi: 10.1038/s41377-020-00375-8
Optical coherence tomography offers astounding opportunities to image the complex structure of living tissue but lacks functional information. We present dynamic full-field optical coherence tomography as a technique to noninvasively image living human induced pluripotent stem cell-derived retinal organoids. Coloured images with an endogenous contrast linked to organelle motility are generated, with submicrometre spatial resolution and millisecond temporal resolution, creating a way to identify specific cell types in living tissue via their function.
Artificial gauge field switching using orbital angular momentum modes in optical waveguides
Christina Jörg, Gerard Queraltó, Mark Kremer, Gerard Pelegrí, Julian Schulz, et al.
Published. 2020, 9(5) : 1315-1321 doi: 10.1038/s41377-020-00385-6
The discovery of artificial gauge fields controlling the dynamics of uncharged particles that otherwise elude the influence of standard electromagnetic fields has revolutionised the field of quantum simulation. Hence, developing new techniques to induce these fields is essential to boost quantum simulation of photonic structures. Here, we experimentally demonstrate the generation of an artificial gauge field in a photonic lattice by modifying the topological charge of a light beam, overcoming the need to modify the geometry along the evolution or impose external fields. In particular, we show that an effective magnetic flux naturally appears when a light beam carrying orbital angular momentum is injected into a waveguide lattice with a diamond chain configuration. To demonstrate the existence of this flux, we measure an effect that derives solely from the presence of a magnetic flux, the Aharonov-Bohm caging effect, which is a localisation phenomenon of wavepackets due to destructive interference. Therefore, we prove the possibility of switching on and off artificial gauge fields just by changing the topological charge of the input state, paving the way to accessing different topological regimes in a single structure, which represents an important step forward for optical quantum simulation.
Incoherent excess noise spectrally encodes broadband light sources
Aaron M. Kho, Tingwei Zhang, Jun Zhu, Conrad W. Merkle, Vivek J. Srinivasan
Published. 2020, 9(5) : 1322-1330 doi: 10.1038/s41377-020-00404-6
Across optics and photonics, excess intensity noise is often considered a liability. Here, we show that excess noise in broadband supercontinuum and superluminescent diode light sources encodes each spectral channel with unique intensity fluctuations, which actually serve a useful purpose. Specifically, we report that excess noise correlations can both characterize the spectral resolution of spectrometers and enable cross-calibration of their wavelengths across a broad bandwidth. Relative to previous methods that use broadband interferometry and narrow linewidth lasers to characterize and calibrate spectrometers, our approach is simple, comprehensive, and rapid enough to be deployed during spectrometer alignment. First, we employ this approach to aid alignment and reduce the depth-dependent degradation of the sensitivity and axial resolution in a spectrometer-based optical coherence tomography (OCT) system, revealing a new outer retinal band. Second, we achieve a pixel-to-pixel correspondence between two otherwise disparate spectrometers, enabling a robust comparison of their respective measurements. Thus, excess intensity noise has useful applications in optics and photonics.
Electromagnetic chirality: from fundamentals to nontraditional chiroptical phenomena
Jungho Mun, Minkyung Kim, Younghwan Yang, Trevon Badloe, Jincheng Ni, et al.
Published. 2020, 9(5) : 1331-1348 doi: 10.1038/s41377-020-00367-8
Chirality arises universally across many different fields. Recent advancements in artificial nanomaterials have demonstrated chiroptical responses that far exceed those found in natural materials. Chiroptical phenomena are complicated processes that involve transitions between states with opposite parities, and solid interpretations of these observations are yet to be clearly provided. In this review, we present a comprehensive overview of the theoretical aspects of chirality in light, nanostructures, and nanosystems and their chiroptical interactions. Descriptions of observed chiroptical phenomena based on these fundamentals are intensively discussed. We start with the strong intrinsic and extrinsic chirality in plasmonic nanoparticle systems, followed by enantioselective sensing and optical manipulation, and then conclude with orbital angular momentum-dependent responses. This review will be helpful for understanding the mechanisms behind chiroptical phenomena based on underlying chiral properties and useful for interpreting chiroptical systems for further studies.
Original Articles
Ultrafast hydrogen bond dynamics of liquid water revealed by terahertz-induced transient birefringence
Hang Zhao, Yong Tan, Liangliang Zhang, Rui Zhang, Mostafa Shalaby, et al.
Published. 2020, 9(5) : 1349-1358 doi: 10.1038/s41377-020-00370-z
The fundamental properties of water molecules, such as their molecular polarizability, have not yet been clarified. The hydrogen bond network is generally considered to play an important role in the thermodynamic properties of water. The terahertz (THz) Kerr effect technique, as a novel tool, is expected to be useful in exploring the low-frequency molecular dynamics of liquid water. Here, we use an intense and ultrabroadband THz pulse (peak electric field strength of 14.9 MV/cm, centre frequency of 3.9 THz, and bandwidth of 1–10 THz) to resonantly excite intermolecular modes of liquid water. Bipolar THz field-induced transient birefringence signals are observed in a free-flowing water film. We propose a hydrogen bond harmonic oscillator model associated with the dielectric susceptibility and combine it with the Lorentz dynamic equation to investigate the intermolecular structure and dynamics of liquid water. We mainly decompose the bipolar signals into a positive signal caused by hydrogen bond stretching vibration and a negative signal caused by hydrogen bond bending vibration, indicating that the polarizability perturbation of water presents competing contributions under bending and stretching conditions. A Kerr coefficient equation related to the intermolecular modes of water is established. The ultrafast intermolecular hydrogen bond dynamics of water revealed by an ultrabroadband THz pump pulse can provide further insights into the transient structure of liquid water corresponding to the pertinent modes.
Diffraction-limited imaging with monolayer 2D material-based ultrathin flat lenses
Han Lin, Zai-Quan Xu, Guiyuan Cao, Yupeng Zhang, Jiadong Zhou, et al.
Published. 2020, 9(5) : 1359-1369 doi: 10.1038/s41377-020-00374-9
Ultrathin flat optics allow control of light at the subwavelength scale that is unmatched by traditional refractive optics. To approach the atomically thin limit, the use of 2D materials is an attractive possibility due to their high refractive indices. However, achievement of diffraction-limited focusing and imaging is challenged by their thickness-limited spatial resolution and focusing efficiency. Here we report a universal method to transform 2D monolayers into ultrathin flat lenses. Femtosecond laser direct writing was applied to generate local scattering media inside a monolayer, which overcomes the longstanding challenge of obtaining sufficient phase or amplitude modulation in atomically thin 2D materials. We achieved highly efficient 3D focusing with subwavelength resolution and diffraction-limited imaging. The high focusing performance even allows diffraction-limited imaging at different focal positions with varying magnifications. Our work paves the way for downscaling of optical devices using 2D materials and reports an unprecedented approach for fabricating ultrathin imaging devices.
Observation of supersymmetric pseudo-Landau levels in strained microwave graphene
Matthieu Bellec, Charles Poli, Ulrich Kuhl, Fabrice Mortessagne, Henning Schomerus
Published. 2020, 9(5) : 1410-1416 doi: 10.1038/s41377-020-00351-2
Using an array of coupled microwave resonators arranged in a deformed honeycomb lattice, we experimentally observe the formation of pseudo-Landau levels in the whole crossover from vanishing to large pseudomagnetic field strengths. This result is achieved by utilising an adaptable setup in a geometry that is compatible with the pseudo-Landau levels at all field strengths. The adopted approach enables us to observe the fully formed flat-band pseudo-Landau levels spectrally as sharp peaks in the photonic density of states and image the associated wavefunctions spatially, where we provide clear evidence for a characteristic nodal structure reflecting the previously elusive supersymmetry in the underlying low-energy theory. In particular, we resolve the full sublattice polarisation of the anomalous 0th pseudo-Landau level, which reveals a deep connection to zigzag edge states in the unstrained case.
Nontrivial coupling of light into a defect: the interplay of nonlinearity and topology
Shiqi Xia, Dario Jukić, Nan Wang, Daria Smirnova, Lev Smirnov, et al.
Published. 2020, 9(5) : 1417-1426 doi: 10.1038/s41377-020-00371-y
The flourishing of topological photonics in the last decade was achieved mainly due to developments in linear topological photonic structures. However, when nonlinearity is introduced, many intriguing questions arise. For example, are there universal fingerprints of the underlying topology when modes are coupled by nonlinearity, and what can happen to topological invariants during nonlinear propagation? To explore these questions, we experimentally demonstrate nonlinearity-induced coupling of light into topologically protected edge states using a photonic platform and develop a general theoretical framework for interpreting the mode-coupling dynamics in nonlinear topological systems. Performed on laser-written photonic Su-Schrieffer-Heeger lattices, our experiments show the nonlinear coupling of light into a nontrivial edge or interface defect channel that is otherwise not permissible due to topological protection. Our theory explains all the observations well. Furthermore, we introduce the concepts of inherited and emergent nonlinear topological phenomena as well as a protocol capable of revealing the interplay of nonlinearity and topology. These concepts are applicable to other nonlinear topological systems, both in higher dimensions and beyond our photonic platform.
Direct observation of photonic Landau levels and helical edge states in strained honeycomb lattices
Omar Jamadi, Elena Rozas, Grazia Salerno, Marijana Milićević, Tomoki Ozawa, et al.
Published. 2020, 9(5) : 1427-1436 doi: 10.1038/s41377-020-00377-6
We report the realization of a synthetic magnetic field for photons and polaritons in a honeycomb lattice of coupled semiconductor micropillars. A strong synthetic field is induced in both the s and p orbital bands by engineering a uniaxial hopping gradient in the lattice, giving rise to the formation of Landau levels at the Dirac points. We provide direct evidence of the sublattice symmetry breaking of the lowest-order Landau level wavefunction, a distinctive feature of synthetic magnetic fields. Our realization implements helical edge states in the gap between n = 0 and n = ±1 Landau levels, experimentally demonstrating a novel way of engineering propagating edge states in photonic lattices. In light of recent advances in the enhancement of polariton–polariton nonlinearities, the Landau levels reported here are promising for the study of the interplay between pseudomagnetism and interactions in a photonic system.
Octupole corner state in a three-dimensional topological circuit
Shuo Liu, Shaojie Ma, Qian Zhang, Lei Zhang, Cheng Yang, et al.
Published. 2020, 9(5) : 1437-1445 doi: 10.1038/s41377-020-00381-w
Higher-order topological insulators (HOTIs) represent a new family of topological materials featuring quantized bulk polarizations and zero-dimensional corner states. In recent years, zero-dimensional corner states have been demonstrated in two-dimensional systems in the form of quadrupole modes or dipole modes. Due to the challenges in designing and constructing three-dimensional systems, octupole corner modes in 3D have not been observed. In this work, we experimentally investigate octupole topological phases in a three-dimensional electrical circuit, which can be viewed as a cubic lattice version of the Hofstadter model with a π-flux threading each plaquette. We experimentally observe in our higher-order topological circuit a 0D corner state manifested as a localized impedance peak. The observed corner state in the electrical circuit is induced by the octupole moment of the bulk circuit and is topologically protected by anticommuting spatial symmetries of the circuit lattice. Our work provides a platform for investigating higher-order topological effects in three-dimensional electrical circuits.
Routing valley exciton emission of a WS2 monolayer via delocalized Bloch modes of in-plane inversion-symmetry-broken photonic crystal slabs
Jiajun Wang, Han Li, Yating Ma, Maoxiong Zhao, Wenzhe Liu, et al.
Published. 2020, 9(5) : 1446-1453 doi: 10.1038/s41377-020-00387-4
The valleys of two-dimensional transition metal dichalcogenides (TMDCs) offer a new degree of freedom for information processing. To take advantage of this valley degree of freedom, on the one hand, it is feasible to control valleys by utilizing different external stimuli, such as optical and electric fields. On the other hand, nanostructures are also used to separate the valleys by near-field coupling. However, for both of the above methods, either the required low-temperature environment or low degree of coherence properties limit their further applications. Here, we demonstrate that all-dielectric photonic crystal (PhC) slabs without in-plane inversion symmetry (C2 symmetry) can separate and route valley exciton emission of a WS2 monolayer at room temperature. Coupling with circularly polarized photonic Bloch modes of such PhC slabs, valley photons emitted by a WS2 monolayer are routed directionally and are efficiently separated in the far field. In addition, far-field emissions are directionally enhanced and have long-distance spatial coherence properties.
Harnessing a multi-dimensional fibre laser using genetic wavefront shaping
Xiaoming Wei, Joseph C. Jing, Yuecheng Shen, Lihong V. Wang
Published. 2020, 9(5) : 1454-1463 doi: 10.1038/s41377-020-00383-8
The multi-dimensional laser is a fascinating platform not only for the discovery and understanding of new higher-dimensional coherent lightwaves but also for the frontier study of the complex three-dimensional (3D) nonlinear dynamics and solitary waves widely involved in physics, chemistry, biology and materials science. Systemically controlling coherent lightwave oscillation in multi-dimensional lasers, however, is challenging and has largely been unexplored; yet, it is crucial for both designing 3D coherent light fields and unveiling any underlying nonlinear complexities. Here, for the first time, we genetically harness a multi-dimensional fibre laser using intracavity wavefront shaping technology such that versatile lasing characteristics can be manipulated. We demonstrate that the output power, mode profile, optical spectrum and mode-locking operation can be genetically optimized by appropriately designing the objective function of the genetic algorithm. It is anticipated that this genetic and systematic intracavity control technology for multi-dimensional lasers will be an important step for obtaining high-performance 3D lasing and presents many possibilities for exploring multi-dimensional nonlinear dynamics and solitary waves that may enable new applications.
Tuneable red, green, and blue single-mode lasing in heterogeneously coupled organic spherical microcavities
Yuxiang Du, Chang-Ling Zou, Chunhuan Zhang, Kang Wang, Chan Qiao, et al.
Published. 2020, 9(5) : 1464-1472 doi: 10.1038/s41377-020-00392-7
Tuneable microlasers that span the full visible spectrum, particularly red, green, and blue (RGB) colors, are of crucial importance for various optical devices. However, RGB microlasers usually operate in multimode because the mode selection strategy cannot be applied to the entire visible spectrum simultaneously, which has severely restricted their applications in on-chip optical processing and communication. Here, an approach for the generation of tuneable multicolor single-mode lasers in heterogeneously coupled microresonators composed of distinct spherical microcavities is proposed. With each microcavity serving as both a whispering-gallery-mode (WGM) resonator and a modulator for the other microcavities, a single-mode laser has been achieved. The colors of the single-mode lasers can be freely designed by changing the optical gain in coupled cavities owing to the flexibility of the organic materials. Benefiting from the excellent compatibility, distinct color-emissive microspheres can be integrated to form a heterogeneously coupled system, where tuneable RGB single-mode lasing is realized owing to the capability for optical coupling between multiple resonators. Our findings provide a comprehensive understanding of the lasing modulation that might lead to innovation in structure designs for photonic integration.
Multifocal structured illumination optoacoustic microscopy
Zhenyue Chen, Ali Özbek, Johannes Rebling, Quanyu Zhou, Xosé Luís Deán-Ben, et al.
Published. 2020, 9(5) : 1473-1481 doi: 10.1038/s41377-020-00390-9
Optoacoustic (OA) imaging has the capacity to effectively bridge the gap between macroscopic and microscopic realms in biological imaging. High-resolution OA microscopy has so far been performed via point-by-point scanning with a focused laser beam, thus greatly restricting the achievable imaging speed and/or field of view. Herein we introduce multifocal structured illumination OA microscopy (MSIOAM) that attains real-time 3D imaging speeds. For this purpose, the excitation laser beam is shaped to a grid of focused spots at the tissue surface by means of a beamsplitting diffraction grating and a condenser and is then scanned with an acousto-optic deflector operating at kHz rates. In both phantom and in vivo mouse experiments, a 10 mm wide volumetric field of view was imaged with 15 Hz frame rate at 28 μm spatial resolution. The proposed method is expected to greatly aid in biological investigations of dynamic functional, kinetic, and metabolic processes across multiple scales.
One photon-per-bit receiver using near-noiseless phase-sensitive amplification
Ravikiran Kakarla, Jochen Schröder, Peter A. Andrekson
Published. 2020, 9(5) : 1482-1488 doi: 10.1038/s41377-020-00389-2
Space communication for deep-space missions, inter-satellite data transfer and Earth monitoring requires high-speed data connectivity. The reach is fundamentally dictated by the available transmission power, the aperture size, and the receiver sensitivity. A transition from radio-frequency links to optical links is now seriously being considered, as this greatly reduces the channel loss caused by diffraction. A widely studied approach uses power-efficient formats along with nanowire-based photon-counting receivers cooled to a few Kelvins operating at speeds below 1 Gb/s. However, to achieve the multi-Gb/s data rates that will be required in the future, systems relying on pre-amplified receivers together with advanced signal generation and processing techniques from fibre communications are also considered. The sensitivity of such systems is largely determined by the noise figure (NF) of the pre-amplifier, which is theoretically 3 dB for almost all amplifiers. Phase-sensitive optical amplifiers (PSAs) with their uniquely low NF of 0 dB promise to provide the best possible sensitivity for Gb/s-rate long-haul free-space links. Here, we demonstrate a novel approach using a PSA-based receiver in a free-space transmission experiment with an unprecedented bit-error-free, black-box sensitivity of 1 photon-per-information-bit (PPB) at an information rate of 10.5 Gb/s. The system adopts a simple modulation format (quadrature-phase-shift keying, QPSK), standard digital signal processing for signal recovery and forward-error correction and is straightforwardly scalable to higher data rates.
Hybridisation of perovskite nanocrystals with organic molecules for highly efficient liquid scintillators
Sangeun Cho, Sungwoo Kim, Jongmin Kim, Yongcheol Jo, Ilhwan Ryu, et al.
Published. 2020, 9(5) : 1489-1497 doi: 10.1038/s41377-020-00391-8
Compared with solid scintillators, liquid scintillators have limited capability in dosimetry and radiography due to their relatively low light yields. Here, we report a new generation of highly efficient and low-cost liquid scintillators constructed by surface hybridisation of colloidal metal halide perovskite CsPbA3 (A: Cl, Br, I) nanocrystals (NCs) with organic molecules (2, 5-diphenyloxazole). The hybrid liquid scintillators, compared to state-of-the-art CsI and Gd2O2S, demonstrate markedly highly competitive radioluminescence quantum yields under X-ray irradiation typically employed in diagnosis and treatment. Experimental and theoretical analyses suggest that the enhanced quantum yield is associated with X-ray photon-induced charge transfer from the organic molecules to the NCs. High-resolution X-ray imaging is demonstrated using a hybrid CsPbBr3 NC-based liquid scintillator. The novel X-ray scintillation mechanism in our hybrid scintillators could be extended to enhance the quantum yield of various types of scintillators, enabling low-dose radiation detection in various fields, including fundamental science and imaging.
Deep-blue organic light-emitting diodes based on a doublet df transition cerium(III) complex with 100% exciton utilization efficiency
Liding Wang, Zifeng Zhao, Ge Zhan, Huayi Fang, Hannan Yang, et al.
Published. 2020, 9(5) : 1498-1506 doi: 10.1038/s41377-020-00395-4
Compared to red and green organic light-emitting diodes (OLEDs), blue OLEDs are still the bottleneck due to the lack of efficient emitters with simultaneous high exciton utilization efficiency (EUE) and short excited-state lifetime. Different from the fluorescence, phosphorescence, thermally activated delayed fluorescence (TADF), and organic radical materials traditionally used in OLEDs, we demonstrate herein a new type of emitter, cerium(III) complex Ce-1 with spin-allowed and parity-allowed df transition of the centre Ce3+ ion. The compound exhibits a high EUE up to 100% in OLEDs and a short excited-state lifetime of 42 ns, which is considerably faster than that achieved in efficient phosphorescence and TADF emitters. The optimized OLEDs show an average maximum external quantum efficiency (EQE) of 12.4% and Commission Internationale de L'Eclairage (CIE) coordinates of (0.146, 0.078).
Tailoring the lineshapes of coupled plasmonic systems based on a theory derived from first principles
Jing Lin, Meng Qiu, Xiyue Zhang, Huijie Guo, Qingnan Cai, et al.
Published. 2020, 9(5) : 1507-1517 doi: 10.1038/s41377-020-00386-5
Coupled photonic systems exhibit intriguing optical responses attracting intensive attention, but available theoretical tools either cannot reveal the underlying physics or are empirical in nature. Here, we derive a rigorous theoretical framework from first principles (i.e., Maxwell's equations), with all parameters directly computable via wave function integrations, to study coupled photonic systems containing multiple resonators. Benchmark calculations against Mie theory reveal the physical meanings of the parameters defined in our theory and their mutual relations. After testing our theory numerically and experimentally on a realistic plasmonic system, we show how to utilize it to freely tailor the lineshape of a coupled system, involving two plasmonic resonators exhibiting arbitrary radiative losses, particularly how to create a completely "dark" mode with vanishing radiative loss (e.g., a bound state in continuum). All theoretical predictions are quantitatively verified by our experiments at near-infrared frequencies. Our results not only help understand the profound physics in such coupled photonic systems, but also offer a powerful tool for fast designing functional devices to meet diversified application requests.
Single-photon emission from isolated monolayer islands of InGaN
Xiaoxiao Sun, Ping Wang, Tao Wang, Ling Chen, Zhaoying Chen, et al.
Published. 2020, 9(5) : 1518-1524 doi: 10.1038/s41377-020-00393-6
We identify and characterize a novel type of quantum emitter formed from InGaN monolayer islands grown using molecular beam epitaxy and further isolated via the fabrication of an array of nanopillar structures. Detailed optical analysis of the characteristic emission spectrum from the monolayer islands is performed, and the main transmission is shown to act as a bright, stable, and fast single-photon emitter with a wavelength of ~400 nm.
A versatile photodetector assisted by photovoltaic and bolometric effects
Wei Jiang, Tan Zheng, Binmin Wu, Hanxue Jiao, Xudong Wang, et al.
Published. 2020, 9(5) : 1525-1533 doi: 10.1038/s41377-020-00396-3
The advent of low-dimensional materials with peculiar structure and superb band properties provides a new canonical form for the development of photodetectors. However, the limited exploitation of basic properties makes it difficult for devices to stand out. Here, we demonstrate a hybrid heterostructure with ultrathin vanadium dioxide film and molybdenum ditelluride nanoflake. Vanadium dioxide is a classical semiconductor with a narrow bandgap, a high temperature coefficient of resistance, and phase transformation. Molybdenum ditelluride, a typical two-dimensional material, is often used to construct optoelectronic devices. The heterostructure can realize three different functional modes: (i) the p–n junction exhibits ultrasensitive detection (450 nm–2 μm) with a dark current down to 0.2 pA and a response time of 17 μs, (ii) the Schottky junction works stably under extreme conditions such as a high temperature of 400 K, and (iii) the bolometer shows ultrabroad spectrum detection exceeding 10 μm. The flexible switching between the three modes makes the heterostructure a potential candidate for next-generation photodetectors from visible to longwave infrared radiation (LWIR). This type of photodetector combines versatile detection modes, shedding light on the hybrid application of novel and traditional materials, and is a prototype of advanced optoelectronic devices.
Black phosphorus-based photothermal therapy with aCD47-mediated immune checkpoint blockade for enhanced cancer immunotherapy
Zhongjian Xie, Minhua Peng, Ruitao Lu, Xiangying Meng, Weiyuan Liang, et al.
Published. 2020, 9(5) : 1534-1548 doi: 10.1038/s41377-020-00388-3
Here, we describe a combination strategy of black phosphorus (BP)-based photothermal therapy together with anti-CD47 antibody (aCD47)-based immunotherapy to synergistically enhance cancer treatment. Tumour resistance to immune checkpoint blockades in most cancers due to immune escape from host surveillance, along with the initiation of metastasis through immunosuppressive cells in the tumour microenvironment, remains a significant challenge for cancer immunotherapy. aCD47, an agent for CD47/SIRPα axis blockade, induces modest phagocytic activity and a low response rate for monotherapy, resulting in failures in clinical trials. We showed that BP-mediated ablation of tumours through photothermal effects could serve as an effective strategy for specific immunological stimulation, improving the inherently poor immunogenicity of tumours, which is particularly useful for enhancing cancer immunotherapy. BP in combination with aCD47 blockade activates both innate and adaptive immunities and promotes local and systemic anticancer immune responses, thus offering a synergistically enhanced effect in suppression of tumour progression and in inducing abscopal effects for inhibition of metastatic cancers. Our combination strategy provides a promising platform in which photothermal agents could help to enhance the therapeutic efficacy of immunotherapy.
Spectrum projection with a bandgap-gradient perovskite cell for colour perception
Mei-Na Zhang, Xiaohan Wu, Antoine Riaud, Xiao-Lin Wang, Fengxian Xie, et al.
Published. 2020, 9(5) : 1549-1561 doi: 10.1038/s41377-020-00400-w
Optoelectronic devices for light or spectral signal detection are desired for use in a wide range of applications, including sensing, imaging, optical communications, and in situ characterization. However, existing photodetectors indicate only light intensities, whereas multiphotosensor spectrometers require at least a chip-level assembly and can generate redundant signals for applications that do not need detailed spectral information. Inspired by human visual and psychological light perceptions, the compression of spectral information into representative intensities and colours may simplify spectrum processing at the device level. Here, we propose a concept of spectrum projection using a bandgap-gradient semiconductor cell for intensity and colour perception. Bandgap-gradient perovskites, prepared by a halide-exchanging method via dipping in a solution, are developed as the photoactive layer of the cell. The fabricated cell produces two output signals: one shows linear responses to both photon energy and flux, while the other depends on only photon flux. Thus, by combining the two signals, the single device can project the monochromatic and broadband spectra into the total photon fluxes and average photon energies (i.e., intensities and hues), which are in good agreement with those obtained from a commercial photodetector and spectrometer. Under changing illumination in real time, the prepared device can instantaneously provide intensity and hue results. In addition, the flexibility and chemical/bio-sensing of the device via colour comparison are demonstrated. Therefore, this work shows a human visual-like method of spectrum projection and colour perception based on a single device, providing a paradigm for high-efficiency spectrum-processing applications.
Metastatic status of sentinel lymph nodes in breast cancer determined with photoacoustic microscopy via dual-targeting nanoparticles
Yanfeng Dai, Xiang Yu, Jianshuang Wei, Fanxin Zeng, Yiran Li, et al.
Published. 2020, 9(5) : 1562-1577 doi: 10.1038/s41377-020-00399-0
Detection of sentinel lymph nodes (SLNs) is critical to guide the treatment of breast cancer. However, distinguishing metastatic SLNs from normal and inflamed lymph nodes (LNs) during surgical resection remains a challenge. Here, we report a CD44 and scavenger receptor class B1 dual-targeting hyaluronic acid nanoparticle (5K-HA-HPPS) loaded with the near-infra-red fluorescent dye DiR-BOA for SLN imaging in breast cancer. The small sized (~40 nm) self-assembled 5K-HA-HPPSs accumulated rapidly in the SLNs after intradermal injection. Compared with normal popliteal LNs (N-LN), there were ~3.2-fold and ~2.4-fold increases in fluorescence intensity in tumour metastatic SLNs (T-MLN) and inflamed LNs (Inf-LN), respectively, 6 h after nanoparticle inoculation. More importantly, photoacoustic microscopy (PAM) of 5K-HA-HPPS showed a significantly distinct distribution in T-MLN compared with N-LN and Inf-LN. Signals were mainly distributed at the centre of T-MLN but at the periphery of N-LN and Inf-LN. The ratio of PA intensity (R) at the centre of the LNs compared with that at the periphery was 5.93 ± 0.75 for T-MLNs of the 5K-HA-HPPS group, which was much higher than that for the Inf-LNs (R = 0.2 ± 0.07) and N-LNs (R = 0.45 ± 0.09). These results suggest that 5K-HA-HPPS injection combined with PAM provides a powerful tool for distinguishing metastatic SLNs from pLNs and inflamed LNs, thus guiding the removal of SLNs during breast cancer surgery.
Perovskite light-emitting/detecting bifunctional fibres for wearable LiFi communication
Qingsong Shan, Changting Wei, Yan Jiang, Jizhong Song, Yousheng Zou, et al.
Published. 2020, 9(5) : 1578-1586 doi: 10.1038/s41377-020-00402-8
Light fidelity (LiFi), which is emerging as a compelling technology paradigm shifting the common means of high-capacity wireless communication technologies, requires wearable and full-duplex compact design because of its great significance in smart wearables as well as the 'Internet of Things'. However, the construction of the key component of wearable full-duplex LiFi, light-emitting/detecting bifunctional fibres, is still challenging because of the conflicting process between carrier separation and recombination, as well as the highly dynamic film-forming process. Here, we demonstrate light-emitting/detecting bifunctional fibres enabled by perovskite QDs with hybrid components. The hybrid perovskite inks endow fibres with super-smooth QD films. This, combined with the small exciton binding energy and high carrier mobility of perovskite QDs, enables successful integration of electroluminescence and photodetection into monofilaments. The bifunctional fibres possess the narrowest electroluminescence full width at half maximum of ~19 nm and, more importantly, the capability for simultaneously transmitting and receiving information. The successful fabrication of narrow emission full-duplex LiFi fibres paves the way for the fabrication and integration of low crosstalk interoperable smart wearables.
Converting lateral scanning into axial focusing to speed up three-dimensional microscopy
Tonmoy Chakraborty, Bingying Chen, Stephan Daetwyler, Bo-Jui Chang, Oliver Vanderpoorten, et al.
Published. 2020, 9(5) : 1587-1598 doi: 10.1038/s41377-020-00401-9
In optical microscopy, the slow axial scanning rate of the objective or the sample has traditionally limited the speed of volumetric imaging. Recently, by conjugating either a movable mirror to the image plane in a remote-focusing geometry or an electrically tuneable lens (ETL) to the back focal plane, rapid axial scanning has been achieved. However, mechanical actuation of a mirror limits the axial scanning rate (usually only 10–100 Hz for piezoelectric or voice coil-based actuators), while ETLs introduce spherical and higher-order aberrations that prevent high-resolution imaging. In an effort to overcome these limitations, we introduce a novel optical design that transforms a lateral-scan motion into a spherical aberration-free axial scan that can be used for high-resolution imaging. Using a galvanometric mirror, we scan a laser beam laterally in a remote-focusing arm, which is then back-reflected from different heights of a mirror in the image space. We characterize the optical performance of this remote-focusing technique and use it to accelerate axially swept light-sheet microscopy by an order of magnitude, allowing the quantification of rapid vesicular dynamics in three dimensions. We also demonstrate resonant remote focusing at 12 kHz with a two-photon raster-scanning microscope, which allows rapid imaging of brain tissues and zebrafish cardiac dynamics with diffraction-limited resolution.
Turning a hot spot into a cold spot: polarization-controlled Fano-shaped local-field responses probed by a quantum dot
Juan Xia, Jianwei Tang, Fanglin Bao, Yongcheng Sun, Maodong Fang, et al.
Published. 2020, 9(5) : 1599-1610 doi: 10.1038/s41377-020-00398-1
Optical nanoantennas can convert propagating light to local fields. The local-field responses can be engineered to exhibit nontrivial features in spatial, spectral and temporal domains, where local-field interferences play a key role. Here, we design nearly fully controllable local-field interferences in the nanogap of a nanoantenna, and experimentally demonstrate that in the nanogap, the spectral dispersion of the local-field response can exhibit tuneable Fano lineshapes with nearly vanishing Fano dips. A single quantum dot is precisely positioned in the nanogap to probe the spectral dispersions of the local-field responses. By controlling the excitation polarization, the asymmetry parameter q of the probed Fano lineshapes can be tuned from negative to positive values, and correspondingly, the Fano dips can be tuned across a broad spectral range. Notably, at the Fano dips, the local-field intensity is strongly suppressed by up to ~50-fold, implying that the hot spot in the nanogap can be turned into a cold spot. The results may inspire diverse designs of local-field responses with novel spatial distributions, spectral dispersions and temporal dynamics, and expand the available toolbox for nanoscopy, spectroscopy, nano-optical quantum control and nanolithography.
Light-modulated vertical heterojunction phototransistors with distinct logical photocurrents
Jiayue Han, Meiyu He, Ming Yang, Qi Han, Fang Wang, et al.
Published. 2020, 9(5) : 1611-1620 doi: 10.1038/s41377-020-00406-4
The intriguing carrier dynamics in graphene heterojunctions have stimulated great interest in modulating the optoelectronic features to realize high-performance photodetectors. However, for most phototransistors, the photoresponse characteristics are modulated with an electrical gate or a static field. In this paper, we demonstrate a graphene/C60/pentacene vertical phototransistor to tune both the photoresponse time and photocurrent based on light modulation. By exploiting the power-dependent multiple states of the photocurrent, remarkable logical photocurrent switching under infrared light modulation occurs in a thick C60 layer (11 nm) device, which implies competition of the photogenerated carriers between graphene/C60 and C60/pentacene. Meanwhile, we observe a complete positive-negative alternating process under continuous 405 nm irradiation. Furthermore, infrared light modulation of a thin C60 (5 nm) device results in a photoresponsivity improvement from 3425 A/W up to 7673 A/W, and we clearly probe the primary reason for the distinct modulation results between the 5 and 11 nm C60 devices. In addition, the tuneable bandwidth of the infrared response from 10 to 3 × 103 Hz under visible light modulation is explored. Such distinct types of optical modulation phenomena and logical photocurrent inversion characteristics pave the way for future tuneable logical photocurrent switching devices and high-performance phototransistors with vertical graphene heterojunction structures.
Opening a new route to multiport coherent XUV sources via intracavity high-order harmonic generation
Natsuki Kanda, Tomohiro Imahoko, Koji Yoshida, Akihiro Tanabashi, A. Amani Eilanlou, et al.
Published. 2020, 9(5) : 1621-1629 doi: 10.1038/s41377-020-00405-5
High-order harmonic generation (HHG) is currently utilized for developing compact table-top radiation sources to provide highly coherent extreme ultraviolet (XUV) and soft X-ray pulses; however, the low repetition rate of fundamental lasers, which is typically in the multi-kHz range, restricts the area of application for such HHG-based radiation sources. Here, we demonstrate a novel method for realizing a MHz-repetition-rate coherent XUV light source by utilizing intracavity HHG in a mode-locked oscillator with an Yb:YAG thin disk laser medium and a 100-m-long ring cavity. We have successfully implemented HHG by introducing two different rare gases into two separate foci and picking up each HH beam. Owing to the two different HH beams generated from one cavity, this XUV light source will open a new route to performing a time-resolved measurement with an XUV-pump and XUV-probe scheme at a MHz-repetition rate with a femtosecond resolution.
Polarimetric parity-time symmetry in a photonic system
Lingzhi Li, Yuan Cao, Yanyan Zhi, Jiejun Zhang, Yuting Zou, et al.
Published. 2020, 9(5) : 1630-1637 doi: 10.1038/s41377-020-00407-3
Parity-time (PT) symmetry has attracted intensive research interest in recent years. PT symmetry is conventionally implemented between two spatially distributed subspaces with identical localized eigenfrequencies and complementary gain and loss coefficients. The implementation is complicated. In this paper, we propose and demonstrate that PT symmetry can be implemented between two subspaces in a single spatial unit based on optical polarimetric diversity. By controlling the polarization states of light in the single spatial unit, the localized eigenfrequencies, gain, loss, and coupling coefficients of two polarimetric loops can be tuned, leading to PT symmetry breaking. As a demonstration, a fiber ring laser based on this concept supporting stable and single-mode lasing without using an ultranarrow bandpass filter is implemented.
Miniscope3D: optimized single-shot miniature 3D fluorescence microscopy
Kyrollos Yanny, Nick Antipa, William Liberti, Sam Dehaeck, Kristina Monakhova, et al.
Published. 2020, 9(5) : 1638-1650 doi: 10.1038/s41377-020-00403-7
Miniature fluorescence microscopes are a standard tool in systems biology. However, widefield miniature microscopes capture only 2D information, and modifications that enable 3D capabilities increase the size and weight and have poor resolution outside a narrow depth range. Here, we achieve the 3D capability by replacing the tube lens of a conventional 2D Miniscope with an optimized multifocal phase mask at the objective's aperture stop. Placing the phase mask at the aperture stop significantly reduces the size of the device, and varying the focal lengths enables a uniform resolution across a wide depth range. The phase mask encodes the 3D fluorescence intensity into a single 2D measurement, and the 3D volume is recovered by solving a sparsity-constrained inverse problem. We provide methods for designing and fabricating the phase mask and an efficient forward model that accounts for the field-varying aberrations in miniature objectives. We demonstrate a prototype that is 17 mm tall and weighs 2.5 grams, achieving 2.76 μm lateral, and 15 μm axial resolution across most of the 900 × 700 × 390 μm3 volume at 40 volumes per second. The performance is validated experimentally on resolution targets, dynamic biological samples, and mouse brain tissue. Compared with existing miniature single-shot volume-capture implementations, our system is smaller and lighter and achieves a more than 2× better lateral and axial resolution throughout a 10× larger usable depth range. Our microscope design provides single-shot 3D imaging for applications where a compact platform matters, such as volumetric neural imaging in freely moving animals and 3D motion studies of dynamic samples in incubators and lab-on-a-chip devices.
Secure optical communication using a quantum alarm
Yupeng Gong, Rupesh Kumar, Adrian Wonfor, Shengjun Ren, Richard V. Penty, et al.
Published. 2020, 9(5) : 1651-1660 doi: 10.1038/s41377-020-00409-1
Optical fibre networks are advancing rapidly to meet growing traffic demands. Security issues, including attack management, have become increasingly important for optical communication networks because of the vulnerabilities associated with tapping light from optical fibre links. Physical layer security often requires restricting access to channels and periodic inspections of link performance. In this paper, we report how quantum communication techniques can be utilized to detect a physical layer attack. We present an efficient method for monitoring the physical layer security of a high-data-rate classical optical communication network using a modulated continuous-variable quantum signal. We describe the theoretical and experimental underpinnings of this monitoring system and the monitoring accuracy for different monitored parameters. We analyse its performance for both unamplified and amplified optical links. The technique represents a novel approach for applying quantum signal processing to practical optical communication networks and compares well with classical monitoring methods. We conclude by discussing the challenges facing its practical application, its differences with respect to existing quantum key distribution methods, and its usage in future secure optical transport network planning.
Multispectral sensing of biological liquids with hollow-core microstructured optical fibres
Timur Ermatov, Roman E. Noskov, Andrey A. Machnev, Ivan Gnusov, Vsevolod Аtkin, et al.
Published. 2020, 9(5) : 1661-1672 doi: 10.1038/s41377-020-00410-8
The state of the art in optical biosensing is focused on reaching high sensitivity at a single wavelength by using any type of optical resonance. This common strategy, however, disregards the promising possibility of simultaneous measurements of a bioanalyte's refractive index over a broadband spectral domain. Here, we address this issue by introducing the approach of in-fibre multispectral optical sensing (IMOS). The operating principle relies on detecting changes in the transmission of a hollow-core microstructured optical fibre when a bioanalyte is streamed through it via liquid cells. IMOS offers a unique opportunity to measure the refractive index at 42 wavelengths, with a sensitivity up to ~3000 nm per refractive index unit (RIU) and a figure of merit reaching 99 RIU−1 in the visible and near-infra-red spectral ranges. We apply this technique to determine the concentration and refractive index dispersion for bovine serum albumin and show that the accuracy meets clinical needs.
Controllable broadband multicolour single-mode polarized laser in a dye-assembled homoepitaxial MOF microcrystal
Huajun He, Yuanjing Cui, Hongjun Li, Kai Shao, Banglin Chen, et al.
Published. 2020, 9(5) : 1370-1379 doi: 10.1038/s41377-020-00376-7
Multicolour single-mode polarized microlasers with visible to near-infrared output have very important applications in photonic integration and multimodal biochemical sensing/imaging but are very difficult to realize. Here, we demonstrate a single crystal with multiple segments based on the host-guest metal-organic framework ZJU-68 hierarchically hybridized with different dye molecules generating controllable single-mode green, red, and near-infrared lasing, with the lasing mode mechanism revealed by computational simulation. The segmented and oriented assembly of different dye molecules within the ZJU-68 microcrystal causes it to act as a shortened resonator, enabling us to achieve dynamically controllable multicolour single-mode lasing with a low three-colour-lasing threshold of ~1.72 mJ/cm2 (approximately seven times lower than that of state-of-the-art designed heterostructure alloys, as reported by Fan F et al. (Nat. Nanotechnol. 10:796–803, 2015) considering the single pulse energy density) and degree of polarization > 99.9%. Furthermore, the resulting three-colour single-mode lasing possesses the largest wavelength coverage of ~186 nm (ranging from ~534 to ~720 nm) ever reported. These findings may open a new route to the exploitation of multicolour single-mode micro/nanolasers constructed by MOF engineering for photonic and biochemical applications.
Opto-thermoelectric microswimmers
Xiaolei Peng, Zhihan Chen, Pavana Siddhartha Kollipara, Yaoran Liu, Jie Fang, et al.
Published. 2020, 9(5) : 1380-1391 doi: 10.1038/s41377-020-00378-5
Inspired by the "run-and-tumble" behaviours of Escherichia coli (E. coli) cells, we develop opto-thermoelectric microswimmers. The microswimmers are based on dielectric-Au Janus particles driven by a self-sustained electrical field that arises from the asymmetric optothermal response of the particles. Upon illumination by a defocused laser beam, the Janus particles exhibit an optically generated temperature gradient along the particle surfaces, leading to an opto-thermoelectrical field that propels the particles. We further discover that the swimming direction is determined by the particle orientation. To enable navigation of the swimmers, we propose a new optomechanical approach to drive the in-plane rotation of Janus particles under a temperature-gradient-induced electrical field using a focused laser beam. Timing the rotation laser beam allows us to position the particles at any desired orientation and thus to actively control the swimming direction with high efficiency. By incorporating dark-field optical imaging and a feedback control algorithm, we achieve automated propelling and navigation of the microswimmers. Our opto-thermoelectric microswimmers could find applications in the study of opto-thermoelectrical coupling in dynamic colloidal systems, active matter, biomedical sensing, and targeted drug delivery.
Lensless light-field imaging through diffuser encoding
Zewei Cai, Jiawei Chen, Giancarlo Pedrini, Wolfgang Osten, Xiaoli Liu, et al.
Published. 2020, 9(5) : 1392-1400 doi: 10.1038/s41377-020-00380-x
Microlens array-based light-field imaging has been one of the most commonly used and effective technologies to record high-dimensional optical signals for developing various potential high-performance applications in many fields. However, the use of a microlens array generally suffers from an intrinsic trade-off between the spatial and angular resolutions. In this paper, we concentrate on exploiting a diffuser to explore a novel modality for light-field imaging. We demonstrate that the diffuser can efficiently angularly couple incident light rays into a detected image without needing any lens. To characterize and analyse this phenomenon, we establish a diffuser-encoding light-field transmission model, in which four-dimensional light fields are mapped into two-dimensional images via a transmission matrix describing the light propagation through the diffuser. Correspondingly, a calibration strategy is designed to flexibly determine the transmission matrix, so that light rays can be computationally decoupled from a detected image with adjustable spatio-angular resolutions, which are unshackled from the resolution limitation of the sensor. The proof-of-concept approach indicates the possibility of using scattering media for lensless four-dimensional light-field recording and processing, not just for two- or three-dimensional imaging.
Wolf phase tomography (WPT) of transparent structures using partially coherent illumination
Xi Chen, Mikhail E. Kandel, Chenfei Hu, Young Jae Lee, Gabriel Popescu
Published. 2020, 9(5) : 1401-1409 doi: 10.1038/s41377-020-00379-4
In 1969, Emil Wolf proposed diffraction tomography using coherent holographic imaging to extract 3D information from transparent, inhomogeneous objects. In the same era, the Wolf equations were first used to describe the propagation correlations associated with partially coherent fields. Combining these two concepts, we present Wolf phase tomography (WPT), which is a method for performing diffraction tomography using partially coherent fields. WPT reconstruction works directly in the space–time domain, without the need for Fourier transformation, and decouples the refractive index (RI) distribution from the thickness of the sample. We demonstrate the WPT principle using the data acquired by a quantitative-phase-imaging method that upgrades an existing phase-contrast microscope by introducing controlled phase shifts between the incident and scattered fields. The illumination field in WPT is partially spatially coherent (emerging from a ring-shaped pupil function) and of low temporal coherence (white light), and as such, it is well suited for the Wolf equations. From three intensity measurements corresponding to different phase-contrast frames, the 3D RI distribution is obtained immediately by computing the Laplacian and second time derivative of the measured complex correlation function. We validate WPT with measurements of standard samples (microbeads), spermatozoa, and live neural cultures. The high throughput and simplicity of this method enables the study of 3D, dynamic events in living cells across the entire multiwell plate, with an RI sensitivity on the order of 10−5.
