2019 Vol. 8, No. 6

Article
Single-cell biomagnifier for optical nanoscopes and nanotweezers
Yuchao Li, Xiaoshuai Liu, Baojun Li
Published. 2019, 8(6) : 966-977 doi: 10.1038/s41377-019-0168-4
Optical microscopes and optical tweezers, which were invented to image and manipulate microscale objects, have revolutionized cellular and molecular biology. However, the optical resolution is hampered by the diffraction limit; thus, optical microscopes and optical tweezers cannot be directly used to image and manipulate nano-objects. The emerging plasmonic/photonic nanoscopes and nanotweezers can achieve nanometer resolution, but the high-index material structures will easily cause mechanical and photothermal damage to biospecimens. Here, we demonstrate subdiffraction-limit imaging and manipulation of nano-objects by a noninvasive device that was constructed by trapping a cell on a fiber tip. The trapped cell, acting as a biomagnifier, could magnify nanostructures with a resolution of 100 nm (λ/5.5) under white-light microscopy. The focus of the biomagnifier formed a nano-optical trap that allowed precise manipulation of an individual nanoparticle with a radius of 50 nm. This biomagnifier provides a high-precision tool for optical imaging, sensing, and assembly of bionanomaterials.
Smart metasurface with self-adaptively reprogrammable functions
Qian Ma, Guo Dong Bai, Hong Bo Jing, Cheng Yang, Lianlin Li, et al.
Published. 2019, 8(6) : 978-989 doi: 10.1038/s41377-019-0205-3
Intelligence at either the material or metamaterial level is a goal that researchers have been pursuing. From passive to active, metasurfaces have been developed to be programmable to dynamically and arbitrarily manipulate electromagnetic (EM) wavefields. However, the programmable metasurfaces require manual control to switch among different functionalities. Here, we put forth a smart metasurface that has self-adaptively reprogrammable functionalities without human participation. The smart metasurface is capable of sensing ambient environments by integrating an additional sensor(s) and can adaptively adjust its EM operational functionality through an unmanned sensing feedback system. As an illustrative example, we experimentally develop a motion-sensitive smart metasurface integrated with a three-axis gyroscope, which can adjust self-adaptively the EM radiation beams via different rotations of the metasurface. We develop an online feedback algorithm as the control software to make the smart metasurface achieve single-beam and multibeam steering and other dynamic reactions adaptively. The proposed metasurface is extendable to other physical sensors to detect the humidity, temperature, illuminating light, and so on. Our strategy will open up a new avenue for future unmanned devices that are consistent with the ambient environment.
Spectral tomographic imaging with aplanatic metalens
Chen Chen, Wange Song, Jia-Wern Chen, Jung-Hsi Wang, Yu Han Chen, et al.
Published. 2019, 8(6) : 990-997 doi: 10.1038/s41377-019-0208-0
Tomography is an informative imaging modality that is usually implemented by mechanical scanning, owing to the limited depth-of-field (DOF) in conventional systems. However, recent imaging systems are working towards more compact and stable architectures; therefore, developing nonmotion tomography is highly desirable. Here, we propose a metalens-based spectral imaging system with an aplanatic GaN metalens (NA = 0.78), in which large chromatic dispersion is used to access spectral focus tuning and optical zooming in the visible spectrum. After the function of wavelength-switched tomography was confirmed on cascaded samples, this aplanatic metalens is utilized to image microscopic frog egg cells and shows excellent tomographic images with distinct DOF features of the cell membrane and nucleus. Our approach makes good use of the large diffractive dispersion of the metalens and develops a new imaging technique that advances recent informative optical devices.
Satellite UV-Vis spectroscopy: implications for air quality trends and their driving forces in China during 2005–2017
Chengxin Zhang, Cheng Liu, Qihou Hu, Zhaonan Cai, Wenjing Su, et al.
Published. 2019, 8(6) : 998-1009 doi: 10.1038/s41377-019-0210-6
Abundances of a range of air pollutants can be inferred from satellite UV-Vis spectroscopy measurements by using the unique absorption signatures of gas species. Here, we implemented several spectral fitting methods to retrieve tropospheric NO2, SO2, and HCHO from the ozone monitoring instrument (OMI), with radiative simulations providing necessary information on the interactions of scattered solar light within the atmosphere. We analyzed the spatial distribution and temporal trends of satellite-observed air pollutants over eastern China during 2005–2017, especially in heavily polluted regions. We found significant decreasing trends in NO2 and SO2 since 2011 over most regions, despite varying temporal features and turning points. In contrast, an overall increasing trend was identified for tropospheric HCHO over these regions in recent years. Furthermore, generalized additive models were implemented to understand the driving forces of air quality trends in China and assess the effectiveness of emission controls. Our results indicated that although meteorological parameters, such as wind, water vapor, solar radiation and temperature, mainly dominated the day-to-day and seasonal fluctuations in air pollutants, anthropogenic emissions played a unique role in the long-term variation in the ambient concentrations of NO2, SO2, and HCHO in the past 13 years. Generally, recent declines in NO2 and SO2 could be attributed to emission reductions due to effective air quality policies, and the opposite trends in HCHO may urge the need to control anthropogenic volatile organic compound (VOC) emissions.
Perturbative countersurveillance metaoptics with compound nanosieves
Jiancai Xue, Zhang-Kai Zhou, Limin Lin, Chao Guo, Shang Sun, et al.
Published. 2019, 8(6) : 1010-1019 doi: 10.1038/s41377-019-0212-4
The progress of metaoptics relies on identifying photonic materials and geometries, the combination of which represents a promising approach to complex and desired optical functionalities. Material candidate options are primarily limited by natural availability. Thus, the search for meta-atom geometries, by either forward or inverse means, plays a pivotal role in achieving more sophisticated phenomena. Past efforts mainly focused on building the geometric library of individual meta-atoms and synthesizing various ones into a design. However, those efforts neglected the powerfulness of perturbative metaoptics due to the perception that perturbations are usually regarded as adverse and in need of being suppressed. Here, we report a perturbation-induced countersurveillance strategy using compound nanosieves mediated by structural and thermal perturbations. Private information can be almost perfectly concealed and camouflaged by the induced thermal-spectral drifts, enabling information storage and exchange in a covert way. This perturbative metaoptics can self-indicate whether the hidden information has been attacked during delivery. Our results establish a perturbative paradigm of securing a safer world of information and internet of things.
Deep spectral learning for label-free optical imaging oximetry with uncertainty quantification
Rongrong Liu, Shiyi Cheng, Lei Tian, Ji Yi
Published. 2019, 8(6) : 1020-1032 doi: 10.1038/s41377-019-0216-0
Measurement of blood oxygen saturation (sO2) by optical imaging oximetry provides invaluable insight into local tissue functions and metabolism. Despite different embodiments and modalities, all label-free optical-imaging oximetry techniques utilize the same principle of sO2-dependent spectral contrast from haemoglobin. Traditional approaches for quantifying sO2 often rely on analytical models that are fitted by the spectral measurements. These approaches in practice suffer from uncertainties due to biological variability, tissue geometry, light scattering, systemic spectral bias, and variations in the experimental conditions. Here, we propose a new data-driven approach, termed deep spectral learning (DSL), to achieve oximetry that is highly robust to experimental variations and, more importantly, able to provide uncertainty quantification for each sO2 prediction. To demonstrate the robustness and generalizability of DSL, we analyse data from two visible light optical coherence tomography (vis-OCT) setups across two separate in vivo experiments on rat retinas. Predictions made by DSL are highly adaptive to experimental variabilities as well as the depth-dependent backscattering spectra. Two neural-network-based models are tested and compared with the traditional least-squares fitting (LSF) method. The DSL-predicted sO2 shows significantly lower mean-square errors than those of the LSF. For the first time, we have demonstrated en face maps of retinal oximetry along with a pixel-wise confidence assessment. Our DSL overcomes several limitations of traditional approaches and provides a more flexible, robust, and reliable deep learning approach for in vivo non-invasive label-free optical oximetry.
Super-resolution localization photoacoustic microscopy using intrinsic red blood cells as contrast absorbers
Jongbeom Kim, Jin Young Kim, Seungwan Jeon, Jin Woo BAIK, Seong Hee Cho, et al.
Published. 2019, 8(6) : 1033-1043 doi: 10.1038/s41377-019-0220-4
Photoacoustic microscopy (PAM) has become a premier microscopy tool that can provide the anatomical, functional, and molecular information of animals and humans in vivo. However, conventional PAM systems suffer from limited temporal and/or spatial resolution. Here, we present a fast PAM system and an agent-free localization method based on a stable and commercial galvanometer scanner with a custom-made scanning mirror (L-PAM-GS). This novel hardware implementation enhances the temporal resolution significantly while maintaining a high signal-to-noise ratio (SNR). These improvements allow us to photoacoustically and noninvasively observe the microvasculatures of small animals and humans in vivo. Furthermore, the functional hemodynamics, namely, the blood flow rate in the microvasculature, is successfully monitored and quantified in vivo. More importantly, thanks to the high SNR and fast B-mode rate (500?Hz), by localizing photoacoustic signals from captured red blood cells without any contrast agent, unresolved microvessels are clearly distinguished, and the spatial resolution is improved by a factor of 2.5 in vivo. L-PAM-GS has great potential in various fields, such as neurology, oncology, and pathology.
3D cellular-resolution imaging in arteries using few-mode interferometry
Biwei Yin, Zhonglie Piao, Kensuke Nishimiya, Chulho Hyun, Joseph A. Gardecki, et al.
Published. 2019, 8(6) : 1044-1052 doi: 10.1038/s41377-019-0211-5
Cross-sectional visualisation of the cellular and subcellular structures of human atherosclerosis in vivo is significant, as this disease is fundamentally caused by abnormal processes that occur at this scale in a depth-dependent manner. However, due to the inherent resolution-depth of focus tradeoff of conventional focusing optics, today's highest-resolution intravascular imaging technique, namely, optical coherence tomography (OCT), is unable to provide cross-sectional images at this resolution through a coronary catheter. Here, we introduce an intravascular imaging system and catheter based on few-mode interferometry, which overcomes the depth of focus limitation of conventional high-numerical-aperture objectives and enables three-dimensional cellular-resolution intravascular imaging in vivo by a submillimetre diameter, flexible catheter. Images of diseased cadaver human coronary arteries and living rabbit arteries were acquired with this device, showing clearly resolved cellular and subcellular structures within the artery wall, such as individual crystals, smooth muscle cells, and inflammatory cells. The capability of this technology to enable cellular-resolution, cross-sectional intravascular imaging will make it possible to study and diagnose human coronary disease with much greater precision in the future.
Low-loss silicon core fibre platform for mid-infrared nonlinear photonics
Haonan Ren, Li Shen, Antoine F. J. Runge, Thomas W. Hawkins, John Ballato, et al.
Published. 2019, 8(6) : 1053-1062 doi: 10.1038/s41377-019-0217-z
Broadband mid-infrared light sources are highly desired for wide-ranging applications that span free-space communications to spectroscopy. In recent years, silicon has attracted great interest as a platform for nonlinear optical wavelength conversion in this region, owing to its low losses (linear and nonlinear) and high stability. However, most research in this area has made use of small core waveguides fabricated from silicon-on-insulator platforms, which suffer from high absorption losses of the use of silica cladding, limiting their ability to generate light beyond 3 μm. Here, we design and demonstrate a compact silicon core, silica-clad waveguide platform that has low losses across the entire silicon transparency window. The waveguides are fabricated from a silicon core fibre that is tapered to engineer mode properties to ensure efficient nonlinear propagation in the core with minimal interaction of the mid-infrared light with the cladding. These waveguides exhibit many of the benefits of fibre platforms, such as a high coupling efficiency and power handling capability, allowing for the generation of mid-infrared supercontinuum spectra with high brightness and coherence spanning almost two octaves (1.6–5.3 μm).
Germanium/perovskite heterostructure for high-performance and broadband photodetector from visible to infrared telecommunication band
Wei Hu, Hui Cong, Wei Huang, Yu Huang, Lijuan Chen, et al.
Published. 2019, 8(6) : 1063-1072 doi: 10.1038/s41377-019-0218-y
A high-performance and broadband heterojunction photodetector has been successfully fabricated. The heterostructure device is based on a uniform and pinhole-free perovskite film constructed on top of a single-crystal germanium layer. The perovskite/germanium photodetector shows enhanced performance and a broad spectrum compared with the single-material-based device. The photon response properties are characterized in detail from the visible to near-infrared spectrum. At an optical fibre communication wavelength of 1550 nm, the heterojunction device exhibits the highest responsivity of 1.4 A/W. The performance is promoted because of an antireflection perovskite coating, the thickness of which is optimized to 150 nm at the telecommunication band. At a visible light wavelength of 680 nm, the device shows outstanding responsivity and detectivity of 228 A/W and 1.6 × 1010 Jones, respectively. These excellent properties arise from the photoconductive gain boost in the heterostructure device. The presented heterojunction photodetector provides a competitive approach for wide-spectrum photodetection from visible to optical communication areas. Based on the distinguished capacity of light detection and harvesting from the visible to near-infrared spectrum, the designed germanium/perovskite heterostructure configuration is believed to provide new building blocks for novel optoelectronic devices.
MATRIEX imaging: multiarea two-photon real-time in vivo explorer
Mengke Yang, Zhenqiao Zhou, Jianxiong Zhang, Shanshan Jia, Tong Li, et al.
Published. 2019, 8(6) : 1073-1083 doi: 10.1038/s41377-019-0219-x
Two-photon laser scanning microscopy has been extensively applied to study in vivo neuronal activity at cellular and subcellular resolutions in mammalian brains. However, the extent of such studies is typically confined to a single functional region of the brain. Here, we demonstrate a novel technique, termed the multiarea two-photon real-time in vivo explorer (MATRIEX), that allows the user to target multiple functional brain regions distributed within a zone of up to 12 mm in diameter, each with a field of view (FOV) of ~200 njm in diameter, thus performing two-photon Ca2+ imaging with single-cell resolution in all of the regions simultaneously. For example, we demonstrate real-time functional imaging of single-neuron activities in the primary visual cortex, primary motor cortex and hippocampal CA1 region of mice in both anesthetized and awake states. A unique advantage of the MATRIEX technique is the configuration of multiple microscopic FOVs that are distributed in three-dimensional space over macroscopic distances (> 1 mm) both laterally and axially but that are imaged by a single conventional laser scanning device. In particular, the MATRIEX technique can be effectively implemented as an add-on optical module for an existing conventional single-beam-scanning two-photon microscope without requiring any modification to the microscope itself. Thus, the MATRIEX technique can be readily applied to substantially facilitate the exploration of multiarea neuronal activity in vivo for studies of brain-wide neural circuit function with single-cell resolution.
Design of task-specific optical systems using broadband diffractive neural networks
Yi Luo, Deniz Mengu, Nezih T. Yardimci, Yair Rivenson, Muhammed Veli, et al.
Published. 2019, 8(6) : 1084-1097 doi: 10.1038/s41377-019-0223-1
Deep learning has been transformative in many fields, motivating the emergence of various optical computing architectures. Diffractive optical network is a recently introduced optical computing framework that merges wave optics with deep-learning methods to design optical neural networks. Diffraction-based all-optical object recognition systems, designed through this framework and fabricated by 3D printing, have been reported to recognize hand-written digits and fashion products, demonstrating all-optical inference and generalization to sub-classes of data. These previous diffractive approaches employed monochromatic coherent light as the illumination source. Here, we report a broadband diffractive optical neural network design that simultaneously processes a continuum of wavelengths generated by a temporally incoherent broadband source to all-optically perform a specific task learned using deep learning. We experimentally validated the success of this broadband diffractive neural network architecture by designing, fabricating and testing seven different multi-layer, diffractive optical systems that transform the optical wavefront generated by a broadband THz pulse to realize (1) a series of tuneable, single-passband and dual-passband spectral filters and (2) spatially controlled wavelength de-multiplexing. Merging the native or engineered dispersion of various material systems with a deep-learning-based design strategy, broadband diffractive neural networks help us engineer the lightɃmatter interaction in 3D, diverging from intuitive and analytical design methods to create task-specific optical components that can all-optically perform deterministic tasks or statistical inference for optical machine learning.
Multiplication and division of the orbital angular momentum of light with diffractive transformation optics
Gianluca Ruffato, Michele Massari, Filippo Romanato
Published. 2019, 8(6) : 1098-1110 doi: 10.1038/s41377-019-0222-2
We present a method to efficiently multiply or divide the orbital angular momentum (OAM) of light beams using a sequence of two optical elements. The key element is represented by an optical transformation mapping the azimuthal phase gradient of the input OAM beam onto a circular sector. By combining multiple circular-sector transformations into a single optical element, it is possible to multiply the value of the input OAM state by splitting and mapping the phase onto complementary circular sectors. Conversely, by combining multiple inverse transformations, the division of the initial OAM value is achievable by mapping distinct complementary circular sectors of the input beam into an equal number of circular phase gradients. Optical elements have been fabricated in the form of phase-only diffractive optics with high-resolution electron-beam lithography. Optical tests confirm the capability of the multiplier optics to perform integer multiplication of the input OAM, whereas the designed dividers are demonstrated to correctly split up the input beam into a complementary set of OAM beams. These elements can find applications for the multiplicative generation of higher-order OAM modes, optical information processing based on OAM beam transmission, and optical routing/switching in telecom.
Sandwich-structure transferable free-form OLEDs for wearable and disposable skin wound photomedicine
Yongmin Jeon, Hye-Ryung Choi, Jeong Hyun Kwon, Seungyeop Choi, Kyung Mi Nam, et al.
Published. 2019, 8(6) : 1111-1125 doi: 10.1038/s41377-019-0221-3
Free-form optoelectronic devices can provide hyper-connectivity over space and time. However, most conformable optoelectronic devices can only be fabricated on flat polymeric materials using low-temperature processes, limiting their application and forms. This paper presents free-form optoelectronic devices that are not dependent on the shape or material. For medical applications, the transferable OLED (10 μm) is formed in a sandwich structure with an ultra-thin transferable barrier (4.8 μm). The results showed that the fabricated sandwich-structure transferable OLED (STOLED) exhibit the same high-efficiency performance on cylindrical-shaped materials and on materials such as textile and paper. Because the neutral axis is freely adjustable using the sandwich structure, the textile-based OLED achieved both folding reliability and washing reliability, as well as a long operating life (> 150 h). When keratinocytes were irradiated with red STOLED light, cell proliferation and cell migration increased by 26 and 32%, respectively. In the skin equivalent model, the epidermis thickness was increased by 39%; additionally, in organ culture, not only was the skin area increased by 14%, but also, re-epithelialization was highly induced. Based on the results, the STOLED is expected to be applicable in various wearable and disposable photomedical devices.
Cooperative interactions between nano-antennas in a high-Q cavity for unidirectional light sources
Kévin G. Cognée, Hugo M. Doeleman, Philippe Lalanne, A. F. Koenderink
Published. 2019, 8(6) : 1138-1151 doi: 10.1038/s41377-019-0227-x
We analyse the resonant mode structure and local density of states in high-Q hybrid plasmonic-photonic resonators composed of dielectric microdisks hybridized with pairs of plasmon antennas that are systematically swept in position through the cavity mode. On the one hand, this system is a classical realization of the cooperative resonant dipole-dipole interaction through a cavity mode, as is evident through predicted and measured resonance linewidths and shifts. At the same time, our work introduces the notion of 'phased array' antenna physics into plasmonic-photonic resonators. We predict that one may construct large local density of states (LDOS) enhancements exceeding those given by a single antenna, which are 'chiral' in the sense of correlating with the unidirectional injection of fluorescence into the cavity. We report an experiment probing the resonances of silicon nitride microdisks decorated with aluminium antenna dimers. Measurements directly confirm the predicted cooperative effects of the coupled dipole antennas as a function of the antenna spacing on the hybrid mode quality factors and resonance conditions.
Bond-selective transient phase imaging via sensing of the infrared photothermal effect
Delong Zhang, Lu Lan, Yeran Bai, Hassaan Majeed, Mikhail E. Kandel, et al.
Published. 2019, 8(6) : 1126-1137 doi: 10.1038/s41377-019-0224-0
Phase-contrast microscopy converts the phase shift of light passing through a transparent specimen, e.g., a biological cell, into brightness variations in an image. This ability to observe structures without destructive fixation or staining has been widely utilized for applications in materials and life sciences. Despite these advantages, phase-contrast microscopy lacks the ability to reveal molecular information. To address this gap, we developed a bond-selective transient phase (BSTP) imaging technique that excites molecular vibrations by infrared light, resulting in a transient change in phase shift that can be detected by a diffraction phase microscope. By developing a time-gated pump-probe camera system, we demonstrate BSTP imaging of live cells at a 50 Hz frame rate with high spectral fidelity, sub-microsecond temporal resolution, and sub-micron spatial resolution. Our approach paves a new way for spectroscopic imaging investigation in biology and materials science.
Quantum expander for gravitational-wave observatories
Mikhail Korobko, Yiqiu Ma, Yanbei Chen, Roman Schnabel
Published. 2019, 8(6) : 1152-1159 doi: 10.1038/s41377-019-0230-2
The quantum uncertainty of laser light limits the sensitivity of gravitational-wave observatories. Over the past 30 years, techniques for squeezing the quantum uncertainty, as well as for enhancing gravitational-wave signals with optical resonators have been invented. Resonators, however, have finite linewidths, and the high signal frequencies that are produced during the highly scientifically interesting ring-down of astrophysical compact-binary mergers still cannot be resolved. Here, we propose a purely optical approach for expanding the detection bandwidth. It uses quantum uncertainty squeezing inside one of the optical resonators, compensating for the finite resonators' linewidths while keeping the low-frequency sensitivity unchanged. This quantum expander is intended to enhance the sensitivity of future gravitational-wave detectors, and we suggest the use of this new tool in other cavity-enhanced metrological experiments.
Full noncontact laser ultrasound: first human data
Xiang Zhang, Jonathan R. Fincke, Charles M. Wynn, Matt R. Johnson, Robert W. Haupt, et al.
Published. 2019, 8(6) : 1198-1208 doi: 10.1038/s41377-019-0229-8
Full noncontact laser ultrasound (LUS) imaging has several distinct advantages over current medical ultrasound (US) technologies: elimination of the coupling mediums (gel/water), operator-independent image quality, improved repeatability, and volumetric imaging. Current light-based ultrasound utilizing tissue-penetrating photoacoustics (PA) generally uses traditional piezoelectric transducers in contact with the imaged tissue or carries an optical fiber detector close to the imaging site. Unlike PA, the LUS design presented here minimizes the optical penetration and specifically restricts optical-to-acoustic energy transduction at the tissue surface, maximizing the generated acoustic source amplitude. With an appropriate optical design and interferometry, any exposed tissue surfaces can become viable acoustic sources and detectors. LUS operates analogously to conventional ultrasound but uses light instead of piezoelectric elements. Here, we present full noncontact LUS results, imaging targets at ~5 cm depths and at a meter-scale standoff from the target surface. Experimental results demonstrating volumetric imaging and the first LUS images on humans are presented, all at eye- and skin-safe optical exposure levels. The progression of LUS imaging from tissue-mimicking phantoms, to excised animal tissue, to humans in vivo is shown, with validation from conventional ultrasound images. The LUS system design insights and results presented here inspire further LUS development and are a significant step toward the clinical implementation of LUS.
Simultaneous emission of orthogonal handedness in circular polarization from a single luminophore
Kyungmin Baek, Dong-Myung Lee, Yu-Jin Lee, Hyunchul Choi, Jeongdae Seo, et al.
Published. 2019, 8(6) : 1160-1167 doi: 10.1038/s41377-019-0232-0
The direct emission of circularly polarized (CP) light improves the efficiency of an organic light-emitting diode and characterizes the secondary structure of proteins. In most cases, CP light is generated from a luminescent layer containing chiral characteristics, thereby generating only one kind of CP light in an entire device. Here, we propose direct CP light emissions using a twisted achiral conjugate polymer without any chiral dopant as an emitting layer (EML). The twisted structure is induced in the mesogenic conjugate polymer due to its elasticity by applying different alignment directions to its upper and lower interfaces. Furthermore, we demonstrate the simultaneous emission of orthogonal CP light in a single luminescent device by patterning different alignment directions on the surfaces of the EML. The light source with multipolarization including the orthogonal CP states is applicable to many applications in biosensors and optical devices.
Stretchable and colorless freestanding microwire arrays for transparent solar cells with flexibility
Sung Bum Kang, Ji-Hwan Kim, Myeong Hoon Jeong, Amit Sanger, Chan Ul Kim, et al.
Published. 2019, 8(6) : 1168-1180 doi: 10.1038/s41377-019-0234-y
Transparent solar cells (TSCs) are emerging devices that combine the advantages of visible transparency and light-to-electricity conversion. Currently, existing TSCs are based predominantly on organics, dyes, and perovskites; however, the rigidity and color-tinted transparent nature of those devices strongly limit the utility of the resulting TSCs for real-world applications. Here, we demonstrate a flexible, color-neutral, and high-efficiency TSC based on a freestanding form of n-silicon microwires (SiMWs). Flat-tip SiMWs with controllable spacing are fabricated via deep-reactive ion etching and embedded in a freestanding transparent polymer matrix. The light transmittance can be tuned from ~10 to 55% by adjusting the spacing between the microwires. For TSCs, a heterojunction is formed with a p-type polymer in the top portion of the n-type flat-tip SiMWs. Ohmic contact with an indium-doped ZnO film occurs at the bottom, and the side surface has an Al2O3 passivation layer. Furthermore, slanted-tip SiMWs are developed by a novel solvent-assisted wet etching method to manipulate light absorption. Finite-difference time-domain simulation revealed that the reflected light from slanted-tip SiMWs helps light-matter interactions in adjacent microwires. The TSC based on the slanted-tip SiMWs demonstrates 8% efficiency at a visible transparency of 10% with flexibility. This efficiency is the highest among Si-based TSCs and comparable with that of state-of-the-art neutral-color TSCs based on organic-inorganic hybrid perovskite and organics. Moreover, unlike others, the stretchable and transparent platform in this study is promising for future TSCs.
Optical frequency synthesizer with an integrated erbium tunable laser
Ming Xin, Nanxi Li, Neetesh Singh, Alfonso Ruocco, Zhan Su, et al.
Published. 2019, 8(6) : 1190-1197 doi: 10.1038/s41377-019-0233-z
Optical frequency synthesizers have widespread applications in optical spectroscopy, frequency metrology, and many other fields. However, their applicability is currently limited by size, cost, and power consumption. Silicon photonics technology, which is compatible with complementary-metal-oxide-semiconductor fabrication processes, provides a low-cost, compact size, lightweight, and low-power-consumption solution. In this work, we demonstrate an optical frequency synthesizer using a fully integrated silicon-based tunable laser. The synthesizer can be self-calibrated by tuning the repetition rate of the internal mode-locked laser. A 20 nm tuning range from 1544 to 1564 nm is achieved with ~10-13 frequency instability at 10 s averaging time. Its flexibility and fast reconfigurability are also demonstrated by fine tuning the synthesizer and generating arbitrary specified patterns over time-frequency coordinates. This work promotes the frequency stability of silicon-based integrated tunable lasers and paves the way toward chip-scale low-cost optical frequency synthesizers.
Nonreciprocal metasurface with space-time phase modulation
Xuexue Guo, Yimin Ding, Yao Duan, Xingjie Ni
Published. 2019, 8(6) : 1181-1189 doi: 10.1038/s41377-019-0225-z
Creating materials with time-variant properties is critical for breaking reciprocity that imposes fundamental limitations on wave propagation. However, it is challenging to realize efficient and ultrafast temporal modulation in a photonic system. Here, leveraging both spatial and temporal phase manipulation offered by an ultrathin nonlinear metasurface, we experimentally demonstrated nonreciprocal light reflection at wavelengths around 860 nm. The metasurface, with travelling-wave modulation upon nonlinear Kerr building blocks, creates spatial phase gradient and multi-terahertz temporal phase wobbling, which leads to unidirectional photonic transitions in both the momentum and energy spaces. We observed completely asymmetric reflections in forward and backward light propagations over a large bandwidth around 5.77 THz within a sub-wavelength interaction length of 150 nm. Our approach highlights a potential means for creating miniaturized and integratable nonreciprocal optical components.
Adding memory to pressure-sensitive phosphors
Robin R. Petit, Simon E. Michels, Ang Feng, Philippe F. Smet
Published. 2019, 8(6) : 1209-1218 doi: 10.1038/s41377-019-0235-x
Mechanoluminescence (ML) is the phenomenon describing the emission of light during mechanical action on a solid, leading to applications such as pressure sensing, damage detection and visualization of stress distributions. In most cases, this mechanical action releases energy that was previously stored in the crystal lattice of the phosphor by means of trapped charge carriers. A drawback is the need to record the ML emission during a pressure event. In this work, we provide a method for adding a memory function to these pressure-sensitive phosphors, allowing an optical readout of the location and intensity of a pressure event in excess of 72 h after the event. This is achieved in the BaSi2O2N2:Eu2+ phosphor, where a broad trap depth distribution essential for the process is present. By merging optically stimulated luminescence (OSL), thermoluminescence (TL) and ML measurements, the influence of light, heat and pressure on the trap depth distribution is carefully analysed. This analysis demonstrates that mechanical action can not only lead to direct light emission but also to a reshuffling of trap occupations. This memory effect not only is expected to lead to new pressure sensing applications but also offers an approach to study charge carrier transitions in energy storage phosphors.
Letter
Biochemical sensing in graphene-enhanced microfiber resonators with individual molecule sensitivity and selectivity
Zhongxu Cao, Baicheng Yao, Chenye Qin, Run Yang, Yanhong Guo, et al.
Published. 2019, 8(6) : 934-943 doi: 10.1038/s41377-019-0213-3
Photonic sensors that are able to detect and track biochemical molecules offer powerful tools for information acquisition in applications ranging from environmental analysis to medical diagnosis. The ultimate aim of biochemical sensing is to achieve both quantitative sensitivity and selectivity. As atomically thick films with remarkable optoelectronic tunability, graphene and its derived materials have shown unique potential as a chemically tunable platform for sensing, thus enabling significant performance enhancement, versatile functionalization and flexible device integration. Here, we demonstrate a partially reduced graphene oxide (prGO) inner-coated and fiber-calibrated Fabry-Perot dye resonator for biochemical detection. Versatile functionalization in the prGO film enables the intracavity fluorescent resonance energy transfer (FRET) to be chemically selective in the visible band. Moreover, by measuring the intermode interference via noise canceled beat notes and locked-in heterodyne detection with Hz-level precision, we achieved individual molecule sensitivity for dopamine, nicotine and single-strand DNA detection. This work combines atomic-layer nanoscience and high-resolution optoelectronics, providing a way toward high-performance biochemical sensors and systems.
Extracting more light for vertical emission: high power continuous wave operation of 1.3-μm quantum-dot photonic-crystal surface-emitting laser based on a flat band
Huan-Yu Lu, Si-Cong Tian, Cun-Zhu Tong, Li-Jie Wang, Jia-Min Rong, et al.
Published. 2019, 8(6) : 944-949 doi: 10.1038/s41377-019-0214-2
For long distance optical interconnects, 1.3-μm surface-emitting lasers are key devices. However, the low output power of several milliwatts limits their application. In this study, by introducing a two-dimensional photonic-crystal and using InAs quantum dots as active materials, a continuous-wave, 13.3-mW output power, 1.3-μm wavelength, room-temperature surface-emitting laser is achieved. In addition, such a device can be operated at high temperatures of up to 90 ℃. The enhanced output power results from the flat band structure of the photonic crystal and an extra feedback mechanism. Surface emission is realized by photonic crystal diffraction and thus the distributed Bragg reflector is eliminated. The proposed device provides a means to overcome the limitations of low-power 1.3-μm surface-emitting lasers and increase the number of applications thereof.
Review Article
Adaptive optics in laser processing
Patrick S. Salter, Martin J. Booth
Published. 2019, 8(6) : 950-965 doi: 10.1038/s41377-019-0215-1
Adaptive optics are becoming a valuable tool for laser processing, providing enhanced functionality and flexibility for a range of systems. Using a single adaptive element, it is possible to correct for aberrations introduced when focusing inside the workpiece, tailor the focal intensity distribution for the particular fabrication task and/or provide parallelisation to reduce processing times. This is particularly promising for applications using ultrafast lasers for three-dimensional fabrication. We review recent developments in adaptive laser processing, including methods and applications, before discussing prospects for the future.
News & Views
Common elements for uncommon light: vector beams with GRIN lenses
Andrew Forbes
Published. 2019, 8(6) : 930-931 doi: 10.1038/s41377-019-0228-9
A well-known defect introduced during the fabrication of GRIN lenses can be exploited for the creation, detection and wave-guiding of exotic forms of vectorial structured light, bringing the toolkit into the realm of common laboratory optics.
Optical microscopy approaches angstrom precision, in 3D!
Shi-Wei Chu
Published. 2019, 8(6) : 932-933 doi: 10.1038/s41377-019-0226-y
By coupling dye molecules with a graphene layer and localizing the molecules through quantification of fluorescence lifetime quenching, a novel imaging system offers unprecedented 1-nm resolution with angstrom precision in the axial dimension.
